What is the problem with the fire pump vibrating or abnormal sound, and how to solve it?
Dec 14, 2022
Share:
The fire-fighting water provided by most fire-fighting water sources needs to be pressurized by fire-fighting water pumps to meet the requirements for water pressure and water volume during fire-fighting, which is an important part of fire-fighting. In daily use, we often encounter fire pumps vibrating or making abnormal noises. What is the problem? How should we solve it?
1. The installation is not firm and the fasteners are loose
After the centrifugal fire pump is started, the impeller will rotate at a high speed. The centrifugal fire pump is not installed firmly, or the fasteners are loosened due to long-term operation, which will cause vibration and noise during the operation of the pump, and even be damaged in a short time.
2. Wear between impeller and seal ring
If the impeller and the sealing ring cannot guarantee a good lubrication state, the wear between the two will increase the gap, and when the gap exceeds a certain value, the pump will cause vibration and noise. The degree of wear increases as the pump runs longer.
3. Improper installation of pump body and pump shaft
The effective energy obtained by the liquid passing through the fire pump is obtained from the impeller of the pump, and the energy obtained by the impeller is obtained from the pump shaft, and the energy obtained by the pump shaft is provided by the motor. When the pump is running, the pump shaft drives the impeller to rotate at high speed. If the pump body and the pump shaft are not installed correctly, the impeller will deviate from the friction with the pump casing, resulting in vibration, and in severe cases, the impeller and pump casing will be damaged.
4. Cavitation causes abnormal sound inside the pump
Excessive resistance of the suction pipeline, leakage of air due to poor sealing, excessive temperature of the liquid being sucked, high flow rate, etc., will cause cavitation, which will cause abnormal sound or severe vibration in the pump.
If your fire pump has vibration and abnormal noise during use, you can refer to the above points to check one by one, and you can easily find out the problem and solve it.
